|Place of Origin:||Guangzhou, China|
|সাক্ষ্যদান:||ISO, CE, BV, SGS|
|Model Number:||VDS05 - VDS100|
|Minimum Order Quantity:||1 set|
|মূল্য:||USD1 - USD999999|
|Packaging Details:||Standard wooden case for the 1 ton cube ice machine|
|Delivery Time:||30 work days|
|Payment Terms:||Western Union, L/C, T/T, MoneyGram|
|Supply Ability:||60 set per month|
|Compressor:||Germany Bitzer/Bock or American Copeland||Refrigerant:||R22/404A|
|Temperature:||0~2 °C or different||Expansion valve:||Danfoss|
|Solenoid valve:||Castal||Tank Material:||SUS304|
|Cooling way:||Air cooling, water cooling||Electricity part:||LG|
Air Cooled Chiller,
Industrial Process Chiller
1. The cold temperature is from 0~2 °c
2. It adopts the flat liquid film exchange heat technology, the area of the exchange heat is large, and the colding speed is fast.
3. It is simple to clean the evaporator, so don't worry that the refrigeration effect gets worse after the dirty of evaporator.
4. It adopts the heat technology to take off the ice, so it needn't to worry the question that low temperature leads evaporator to freeze because it can automatically take off the ice in some time interval.
5. The equipment structure is tight. The cover area is small
6. There are 0.5~5 m3 per hour models to choose
|1. Max. Ambient temp.||+400C|
|3.Supply water temp||230C|
|6.Compressor type||semi-hermetic piston compressor|
|7.Cooling system||water cooling|
|1||Name||low temperature water chiller|
|4||Capacity||Supply 0.5-4℃ low temperature water,5m3/h|
|6||Dimension||Machine: 2800mm x 2500mm x 1800mm|
|11||Necessary cooling capacity||91.7kw|
|12||Input water temp.||230C|
|Model||semi-hermetic piston compressor|
|17||Power||18.84kw x 2|
|18||Total Power of water condenser||7.5KW|
|21||Power of circulating water pump||2.2KW|
|Item||Name of Components||Brand Name||Original Country|
|3||Water cooled condenser||JIANGCHE||China|
|6||PLC Program control||SIMENS||Germany|
|7||Electrical components||LG (LS)||South Korea|
|8||Refrigerant filter - drier||ALCO||America( Mexico)|
|9||Oil filter||Emerson||America ( Mexico )|
|10||High and low pressure meter||Switzerland||Switzerland|
|11||Low and high pressure relay||Danfoss||Denmark|
|13||Titanium tube evaporator||CBFI||China|
1. Standard wooden case.
2. Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
3. Machine come into use, it can be started once electric power and water supply has been connected.
4. All required components for install the machine will be provide.
5.Delivery time: 30 working days
1. We have a strong after-sale service team. All the technicians are experienced, they have been to many countries to serve our customers like you.
2. The warranty of the whole machine is 12 months.
Q1: Why don’t you choose Ammonia as refrigerant ?
A: 1.As we know, Ammonia, with a strong pungent smell, is a toxic refrigerant. It have strong stimulation to our eyes, nose, throat, lung and skin. It can be danger of fire and explosion when the air concentration of ammonia is more than 15%. Therefore, the ammonia refrigeration system come under a rigorous regulatory approvals by the State administration of work safety.
2.Ammonia refrigeration system is complex, and is too risky to operate.So, it need somebody on duty 24 hours,which increase labor costs.
3.A very low automatic degreeand high power consumption of the equipment of Ammonia refrigeration system lead to a high machine running cost.
Q2: What configuration of the voltage of the machine is ?
A: We adopt standard voltage -380V/3P/50Hz usually, non-standard voltage can be customized, the price is extra.
Q3: What’s your usual practice about terms of payment ?
A:The payment can be T/T,L/C,Western Union, Money Gram and in Cash. The deposit is 30%, after we receive your deposit, we will start to produce the machine for you. The balance 70% should be paid before shipping.
Q4: How long is the time of delivery?
A: The delivery time normally is 30 days after we receive the deposit. And If necessary, we will arrange the shipping for you.
